OPAX-4005 5 MP IP (2880X1620) H.265+ 4 WARM LIGHT FULL COLOR 3.6 MM METAL BULLET IP CAMERA
● 1/2,7 Düşük aydınlatmalı Aşamalı Tarama CMOS Sensörü;
● 5 .0MP HD çözünürlük;(2880X1620)
● Katıştırılmış Web Sunucusu, Internet Explorer izleme, yapılandırma ve yükseltmeyi destekler;
● Tüm NVR ları destekler, alt ağları destekler, ONVIF, Kolay bağlantı farklı ağ segmentlerinide destekler
● Android'de Danale APP'yi, P2P ile IOS'u destekler
● P2P ile DANALE NVR kayıt Cihazı olamdan tüm kameralarınızı mobil uygulama üzerinden izleme imkanı
● ONVIF2.6'yı destekler;
● H.265+/H.265/H.264 ana profil kodlaması, iki eşzamanlı video akışı;
● 4 Akıllı çift ışık (warm light) , kızılötesi (ır) , Ir ve Warm Led üç modu isteğe bağlı destekler;
● AI insan algılama desteği, Alan algılama;(danale üzerinden)
● Standart SDK(Linux,Windows),diğer dijital sistemlerle kolayca entegre edilebilir.
● Support H264, H.265,H.265+
● Support dual stream. Main stream : 2880X16620 (15FPS) ,2560X1440 (30 Fps) ,2304x1296 (30fps) ,1920×1080(30fps) ; Sub-stream: D1(704*576)/ 360P(640*360 )/ CIF(352*288), VGA,480X360,( H264, H.265,H.265+)
● Support WDR, 3D-NR, 2D- NR, BLC, HLC, Forced anti-ficker , Day Shutter mode, Night Shutter Mode, image mode ( superstarlıght mode,Defogging (smart)Auto-White balance for different environments
● Support ONVIF, can connect with other companys NVR ;
● ICR switching to surveille 24 hours
● Support image shutter, 4 Shutter areas can be set ;
● Support motion detection, motion detection alarm can be sent to email automatically
● Support OSD setting and network timing
● Support mobile surveillance(iOS, android),Web and VMS ;
● Support self-maintenance
● Support stepless IR, stepless white light mode
OPAX-4005 5 MP IP (2880X1620) H.265+ 4 WARM LIGHT FULL COLOR 3.6 MM METAL BULLET IP CAMERA
Models | OPAX-4005 |
Models | 5 .0MP Ultra low-night HD Network Camera Module |
Image Sensor | 1/2.9 '' 5.0MP |
Min. Illumination | Color:0.0001Lux |
Solition | SSC30KD SC4653 |
WARM LED | 4 Adet Warm LED |
BLC | 1-255 Arası Ayarlanabilir |
HLC | YES (1-255) Arası Ayarlanabilir |
2DNR | 1-255 Arası Ayarlanabilir |
3DNR | 1-255 Arası Ayarlanabilir |
W/B MODE | AUTO/MANUAL |
Day Shutter Mode | Auto And Manual (1/10-1/10000 ) |
Night Shutter Mode | Auto And Manual (1/10-1/10000 ) |
İmage Setting | Support for brightness, contrast, saturation, white balance, AWB (automatic white balance), AGC (automatic gain), AE (automatic exposure); support privacy area; normal / 90° / 270° image rotation; Automatic, manual color to black and other switches |
FORCED ANTI FLICKER | DISABLE /ENABLE |
Horizon Flip | DISABLE /ENABLE |
Vertical Flip | DISABLE /ENABLE |
Defogging | DISABLE /ENABLE |
WDR MODE | YES SUPPORT |
IRCUT MODEL | AUTO/TIMING/EXTERNAL/MANUAL |
KEEP COLOR | YES/ NO SEÇİLEBİLİR |
LIGHT MODE | Pure Infrared light / Pure White light /Open White Light When Infrared Triggered Open Infrared Light When White Lifgt Triggered |
LIGHT IMAGE OPTION | Normal/Prevent Overeexposure/ Licence plate mode 1 to 6 |
LIGHTS OF SENSITIVITY | 1-100 Ayarlanabilir |
LIGHT BRIGHTNESS MODE | Auto / Manual /BRIGHTNESS Restirected |
LIGHT BRIGHTNESS | %10 -%100 |
LED DELAY | 0,001-1,5 |
HTTP Port | 80 ( Ayarlanabilir) |
Control Protocol | 8091( Ayarlanabilir) |
RTSP | 554( Ayarlanabilir) |
HIK PORT | 8000 ( Ayarlanabilir) |
P2P | DANALE Destekler (kayıt Cihazı olmadanda mobil uygulama üzerinden izleme imkanı) |
Hareket Algılama | Destekler |
IO | Input /Output Destekler (Günlük Haftalık program) |
S/N Ratio | ≥37dB |
POE | POE YOK |
Encode Mode | H.265+ / H.265 / H.264 |
Wide Dynamic Range | Digital WDR |
Digital noise Reduction | DNR, 3DNR |
Exposure Mode | Auto/Manual/shutter mode(shutter range variable) |
White Balance | Auto/Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
Day & Night | Day / Night / External control(IR Cut Filter) |
Video Compression | H.265+/H.265/H.264 Main Profile |
Audio Compression | G711U/G711A |
Max. Image Resolution | 2560*1440 at 20fps |
Image Resolution | Main stream :5MP at 15fps, , 4MP (30Fps) ,1080P/720P/D1 at 30fps |
Sub-stream | D1/VGA/640*360/CIF at 30fps |
Streams | Dual streams |
Bitrate | CBR/VBR, bitrate: 50Kbps~6Mbps variable |
Simultaneous Live View | Main stream Up to 5, Sub-stream Up to 5 |
OSD | Support camera name, time display .etc, OSD position can be adjusted |
Motion detect | Support |
IO | Support (pinler board üzerinde mevcut) |
P2P | Android, IOS (Danale) |
Protocols | HTTP, NTP, DHCP, UDNP, RTSP, P2P, ONVIF |
Onvif | Onvif 2.6 |
Network | 10/100M Base-TX Ethernet, RJ45 Connector |
Store | Unsupport |
Protection Level | TVS 6,000V lightning protection |
Power Supply | 12V DC at 0.7A |
Dimensions Board | 38x38mm Single board |
Working Temperature | -30°C ~85°C, Humidity ≤90%RH(Unsupport-condensing) |
